Agilent Technologies Infinity Binary Pump VL 1290

Agilent 1290 Infinity Binary Pump User Manual 125
Maintenance
9
Replacing the Solvent Selection Valve (SSV)
Replacing the Solvent Selection Valve (SSV)
When In case of problems with the solvent selection valve
Parts required # p/n Description
1 G4280-60029 Solvent selection valve
4 G4220-60035 Tubing kit 140 mm SSV to shutoff valve or degassing unit (2 tubes)
1 Close shut-off valve. Remove tubing connections
between the SSV and the solvent shut-off valves and the
SSV and the degassing unit inlets.
2 Push down the SSV panel for removing it.
6
7
7
6
7'
7&
6'
6&
