182 Agilent 1290 Infinity Binary Pump User Manual
10 Parts and Materials for Maintenance
Purge Valve
Purge Valve
Figure 24 Purge valve parts
&
'
(
)
Item p/n Description
5067-4119 Purge valve head
1 1535-4857 Stator screws
2 5068-0004 Purge Valve Stator
3 5068-0005 Purge Valve Rotor Seal, 1200 bar
4 1535-4045 Bearing ring
