Parts and Materials for Maintenance
10
Cover Parts
Cover Parts
Figure 25 Cover Parts
&
'
(
)
Item p/n Description
1 5067-4613 Cabinet Kit (Side Covers left/right, Top Cover, Tubing Plug,
Base Cover and Leak Seal)
2 5042-9949 Tubing Plug, Plastic
5042-9972 Tubing grommet
3 5067-4612 Front Cover 1290 Infinity Binary Pump
4 5067-4634 Valve Rail Kit
