Agilent Technologies Infinity Binary Pump VL 1290

Agilent 1290 Infinity Binary Pump User Manual 129
Maintenance
9
Changing configuration or replacing the Jet Weaver
3
Install new Jet Weaver or flip the Jet Weaver for
backside.
4 Reinstall the capillary connections.
The inlet at the bottom of the Jet Weaver is connected to
the central port of the pump valve by a capillary (length
300 mm, 0.17 mm i.d.). The outlet at the top is connected
to the autosampler.
