Agilent 1290 Infinity Binary Pump User Manual 193

Identifying Cables

Analog cables

Agilent Module to General Purpose

p/n 01046-60105 Pin Pin Agilent

module

Signal Name

1 Not connected

2 Black Analog -

3 Red Analog +
