8AL90608USAGed01 13 / 77
5. Loudspeaker – Controls and displays the status of the loudspeaker.
a. Speaker active.
b. Speaker inactive.
6. Loudspeaker volume – Displays the loudspeaker volume, with six different levels:
Min, Very low, Low, Normal, High and Max.
7. Volume down – Press to decrease the volume
8. Volume up – Press to increase the volume.
9. Auto answer – Displays the automatic answer status. This function is activated in
Guide mode.
a. Automatic answer active. After a specified interval the call will be
answered automatically.
b. Manual answer mode. Operator uses assigned key to answer call.
10. Auto transfer - Displays the automatic transfer status. This function is activated in
Guide mode.
a. Automatic transfer active. Transfer is made automatically when B-part is
reserved.
b. Manual transfer mode. Transfer is made when operator uses the assigned
transfer key.
11. Guide mode – Enters guide mode. Press the button opens the guide mode dialog.
a. Guide mode dialog active.
b. Normal state.
12. Service mode – Enters service mode. Press the button opens the service mode
dialog.
a. Service mode dialog active.
b. Normal state.
13. User message – Displays
a. No message is present.
b. There is one or more message available. Click on the icon in order to open
the text message window to read your messages.
14. Trunk reservation - Indicates the status of the bundle/trunk reservation in the service
mode dialog.
a. Normal state.
b. Trunks reserved by operator.
15. Keyboard type - Indicates the detected keyboard type
a. Standard keyboard detected.
b. Alcatel-Lucent keyboard.
16. Connection state – Indicates the connection to the Alcatel-Lucent OmniPCX
Enterprise.
a. Connected
b. Not connected
