8AL90608USAGed01 33 / 77
11.2 BLF item menu
When you right click on a BLF item, a popup menu is displayed. Here
you have four different choices for the BLF item.
Rename - Click to rename the item, will open the rename dialog. Enter
the new name and click OK to save.
Remove – Click to remove the item. A confirmation dialog will be
displayed before removal.
Dial – Click to dial the extension.
Lock – Click to lock the position of the item. To unlock item click again.
The item is unlocked and can be positioned.
The item is locked.
11.3 OpenTouch BLF
Alcatel Lucent OpenTouch devices can be monitored in Busy Lamp Field. These devices are
added as a regular BLF item. In order for the monitoring to work a Alcatel Lucent OpenTouch
must be configured in OpenTouch settings dialog.
Alcatel Lucent OpenTouch devices can be set to 4 different status;
Idle
Busy
Immediate forward
Forward to Voicemail
When 4059EE is connect to an Alcatel Lucent OpenTouch 2.1.1 presence status from ICS is
displayed when monitor a device.
The available presences are;
Present
Away
Busy
Offline (Offline is displayed without an colored bullet icon).
11.4 Export/Import
In 4059EE you can export all of your BLF items and save them in a file on disk. It is always
good to have file stored on the disk if the BLF, by accident, is in-activated. This since all
items are deleted when the BLF is in-activated and is not restored when the BLF is activated.
To export, click on Export items in the BLF Configuration menu. This will open a Windows
dialog, enter the name of the file and set a location where it should be saved. By default, the
file is named BLFitems.blf.
The file can also be imported on another Alcatel-Lucent 4059EE (or you can import a file
from another Alcatel-Lucent 4059EE on your machine).
