8AL90608USAGed01 20 / 77
7.3 Import and export
The import item dialog is used to restore/load PD entries from a file or on another operator
PC. To import items, click Import. This will bring up a Windows Open file dialog. Choose the
file and click open to execute the import. The files that can be used for import is *.pdx and
*.dat.
If the import resulted in success, the entries are displayed in the Personal Directory
Management.
The export is used to save the PD entries to a file in order to use it as a backup or import
entries from another PC. To export click Export. This will bring up a Windows Save As dialog.
Enter the preferred name of the file and click save to execute the export. The exported file
will be saved as *.pdx.
8 Call handling
The call handling fields consists of two panes where the call information is displayed with text
and graphical symbols.
1. Left call handling pane – The first part is shown in the left field of the call handling.
2. Right call handling pane – The second part is shown in the right field of the call
handling window.
3. Call and device status – The call state is a combination of call status and device
status. The device status is represented by a symbol that is drawn on the top of the
call status.
4. Internal/External – This icon displays if the call is an internal or and external call.
5. Call information – Each window contains up to 6 rows of information;
Calling number & name including forward & association states
Entity
Device status
Call state
Call condition, characteristics and user data (i.e forward to text info,
taxation…)
Plugin container
6. Presence status – If presence is available for the user this is displayed under the call
information
