Allen-Bradley Kinetix 300 - Chapter 6 Configure and Start Up the Kinetix 300 Drive

Rockwell Automation Publication 2097-UM001D-EN-P - November 2012 125
Chapter 6
Configure and Start Up the Kinetix 300 Drive
Topic Page
Keypad Input 126
Configure the Kinetix 300 Drive Ethernet IP Address 128
Configuring the Logix EtherNet/IP Module 132
Apply Power to the Kinetix 300 Drive 138
Test and Tune the Axis 139
Select Drive Operating Mode 142
Master Gearing Mode Examples 143
Configure the Drive Parameters and System Variables 145
Configure Drive Mode with Explicit Messaging 148
Configure Drive for Linear Motors and Direct Drive Stages 150
