Allen-Bradley Kinetix 300 User Manual

22 Rockwell Automation Publication 2097-UM001D-EN-P - November 2012
Chapter 2 Installing the Kinetix 300 Drive System
Circuit Breaker/Fuse Specifications
While circuit breakers offer some convenience, there are limitations for their use.
Circuit breakers do not handle high current inrush as well as fuses.
Make sure the selected components are properly coordinated and meet
acceptable codes including any requirements for branch circuit protection.
Evaluation of the short-circuit available current is critical and must be kept below
the short-circuit current rating of the circuit breaker.
Use class CC or T fast-acting current-limiting type fuses, 200,000 AIC,
preferred. Use Bussmann KTK-R, JJN, JJS or equivalent. Thermal-magnetic type
breakers preferred. The following fuse examples and Allen-Bradley® circuit
breakers are recommended for use with Kinetix 300 drives.
Cat. No.
Drive
Voltage
Main VAC
Bussmann Fuse
Allen-Bradley Circuit Breaker
(1)
(1) When using Bulletin 1492 circuit protection devices, the maximum short circuit current available from the source is limited to
5000 A.
Disconnect
(2)
(2) Use fully-rated short-circuit protection circuit breaker for device branch circuit protection only when there is an upstream fully-rated
breaker.
Magnetic Contactor
(3)
(3) Fully-rated breaker for overload current and short circuit rating.
2097-V31PR0
120V KTK-R-20 (20A) 1492-SP1D200 140M-F8E-C20
240V KTK-R-10 (10A) 1492-SP1D100 140M-F8E-C10
2097-V31PR2
120V KTK-R-30 (30A) 1492-SP1D300 140M-F8E-C32
240V KTK-R-20 (20A) 1492-SP1D200 140M-F8E-C20
2097-V32PR0
240V KTK-R-20 (20A) 1492-SP3D200 140M-F8E-C20
2097-V32PR2
2097-V32PR4 240V KTK-R-30 (30A) 1492-SP3D320 140M-F8E-C32
2097-V33PR1
120V KTK-R-20 (20A) 1492-SP1D200 140M-F8E-C20
240V KTK-R-15 (15A) 1492-SP3D150 140M-F8E-C16
2097-V33PR3
120V KTK-R-20 (20A) 1492-SP1D200 140M-F8E-C20
240V KTK-R-15 (15A) 1492-SP3D150 140M-F8E-C16
2097-V33PR5
120V KTK-R-30 (30A) 1492-SP1D300 140M-F8E-C32
240V KTK-R-20 (20A) 1492-SP3D200 140M-F8E-C20
2097-V33PR6
120V N/A N/A N/A
240V KTK-R-30 (30A) 1492-SP3D300 140M-F8E-C32
2097-V34PR3
480V
KTK-R-10 (10A) 1492-SP3D100 140M-F8E-C10
2097-V34PR5 KTK-R-10 (10A) 1492-SP3D100 140M-F8E-C10
2097-V34PR6 KTK-R-20 (20A) 1492-SP3D200 140M-F8E-C20
