Installing the Kinetix 300 Drive System Chapter 2
Cable Categories for Kinetix 300 Drive Components
These table indicate the zoning requirements of cables connecting to the
Kinetix 300 drive components.
Table 6 - Kinetix 300 Drive Components
Noise Reduction Guidelines for Drive Accessories
See this section when mounting an AC line filter or shunt resistor module for
guidelines designed to reduce system failures caused by excessive electrical noise.
AC Line Filters
Observe these guidelines when mounting your AC line filter:
• If you are using a Bulletin 2090 line filter, mount the filter on the same
panel as the Kinetix 300 drive, and as close to the drive as possible.
• Good HF bonding to the panel is critical. For painted panels, see the
examples on page 27
.
• Segregate input and output wiring as far as possible.
Wire/Cable Connector Zone Method
Very
Dirty
Dirty Clean Ferrite
Sleeve
Shielded
Cable
L1, L2, L3 (unshielded cable) IPD X
U, V, W (motor power) MP X X
+, -, SH (shunt resistor) BC X
24V DC BP X
Control COM, 24V DC control, safety enable, and
feedback signals for safe-off feature
STO X
Motor feedback MF X X
Registration and analog outputs IOD X X
Others X
Ethernet Port 1 X X
