Chapter 1 Start
About the Kinetix 300 Drive
System
The Kinetix 300 EtherNet/IP indexing servo drive is designed to provide a
solution for applications with output power requirements between 0.4…3.0 kW
(2…12 A rms).
Table 1 - Kinetix 300 Drive System Overview
Kinetix 300 System
Component
Cat. No. Description
Kinetix 300 EtherNet/IP
Indexing Servo Drive
2097-V3xPRx Kinetix 300 EtherNet/IP indexing drives with safe torque-off feature are available with 120/240V or 480V AC input
power.
AC Line Filters 2090
2097-Fx
Bulletin 2090 and Bulletin 2097-Fx AC line filters are required to meet CE with Kinetix 300 drives without an
integrated line filter. Bulletin 2097 filters are available in foot mount and side mount.
Shunt Module 2097-Rx Bulletin 2097 shunt resistors connect to the drive and provide shunting capability in regenerative applications.
Terminal block for I/O
connector
2097-TB1 50-pin terminal block. Use with IOD connector for control interface connections.
Memory Module
Programmer
2097-PGMR The EPM programmer is used to duplicate the memory and configuration of the Kinetix 300 drives.
Memory Modules
12 Pack
2097-MEM These removable memory modules are used by the drive to store parameters.
Logix Controller Platform 1769-L23E-xxx
1769-L3xE-xxxx
1768-L4x
1756-L6x
1766-L32xxx
1763-L16xxx
EtherNet/IP interface modules serve as a link between the ControlLogix/CompactLogix/MicroLogix™ platform and the
Kinetix 300 drive system. The communication link uses EtherNet/IP protocol over a copper cable.
RSLogix™ 5000 Software 9324-RLD300ENE RSLogix 5000 software provides support for programming, commissioning, and maintaining the Logix family of
controllers.
Rotary Servo Motors MP-Series™, TL-Series™ Compatible rotary motors include the MP-Series (Bulletin MPL, MPM, MPF, and MPS) and TL-Series motors.
Linear Stages MP-Series Compatible stages include MP-Series (Bulletin MPAS) Integrated Linear Stages.
Linear Actuators LDAT-Series Compatible actuators include LDAT-Series (Bulletin LDAT) Integrated Linear Thrusters.
Linear Motors LDC-Series™, LDL-Series™ Compatible linear motors include LDC-Series and LDL-Series (Bulletin LDC and LDL) Linear Motors.
Electric Cylinders MP-Series, TL-Series Compatible electric cylinders include MP-Series and TL- Series (Bulletin MPAR, TLAR, and MPAI) Electric Cylinders.
Cables Motor/brake and feedback
cables
Motor power/brake and feedback cables include SpeedTec and threaded DIN connectors at the motor. Power/brake
cables have flying leads on the drive end and straight connectors that connect to servo motors. Feedback cables have
flying leads that wire to low-profile connector kits on the drive end and straight connectors on the motor end.
Communication cables 1585J-M8CBJM-x (shielded) Ethernet cable.
