Allen-Bradley MicroLogix 1100 User Manual

Publication 1763-UM001E-EN-P - June 2015
172 Specifications
General Specifications
Specification 1762-IF2OF2 1762-IF4 1762-OF4 1762-IR4 1762-IT4
Shipping weight,
approx. (with
carton)
240 g (0.53 lbs.) 235 g (0.517 lbs.) 260 g (0.57 lbs.) 220 g (0.53 lbs.)
Bus current draw,
max.
40 mA at 5V DC
105 mA at 24V DC
40 mA at 5V DC
50 mA at 24V DC
40 mA at 5V DC
165 mA at 24V DC
40 mA at 5V DC
50 mA at 24V DC
40 mA at 5V DC
50 mA at 24V DC
Analog normal
operating range
Voltage: 0…10V DC
Current: 4…20 mA
Voltage:
-10…+10V DC
Current: 4…20 mA
Voltage 0…10V DC
Current: 4…20 mA
NA NA
Full scale
(1)
analog ranges
Voltage:
0…10.5V DC
Current: 0…21 mA
Voltage:
-10.5…+10.5V DC
Current: -21…+21
mA
Voltage:0…10.5V DC
Current: 0…21 mA
NA NA
Resolution 12 bits (unipolar)
15 bits (bipolar)
(4)
12 bits (unipolar) Input filter and
configuration
dependent
15 bits plus sign
Repeatability
(2)
±0.12%
(4)
±0.12%
(4)
±0.12%
(4)
±0.1 °C (±0.18 °F) for
Ni and NiFe
±0.2 °C
(±0.36 °F)…±0.2 °C
(±0.36 °F) for other
RTD inputs
±0.04 ohm for
150 ohm resistances
±0.2 ohm for other
resistances
See Table 176
Input and output
group to system
isolation
30V AC/30V DC rated working voltage
(3)
(N.E.C. Class 2 required)
(IEC Class 2 reinforced insulation)
type test: 500V AC or 707V DC for 1 minute
30V AC/30V DC rated
working voltage
(IEC Class 2
reinforced insulation)
type test: 500V AC or
707V DC for 1 minute
30V AC/30V DC
working voltage
type test: 500V AC or
707V DC for 1 minute
30V AC/30V DC
working voltage
qualification test:
720V DC for 1 minute
Vendor I.D. code 11111
Product type code 10 10 10 10 10
Product code 75 67 66 65 64
(1) The over- or under-range flag comes on when the normal operating range (over/under) is exceeded. The module continues to convert the analog input up to the maximum
full scale range.
(2) Repeatability is the ability of the module to register the same reading in successive measurements for the same signal.
(3) Rated working voltage is the maximum continuous voltage that can be applied at the terminals with respect to earth ground.
(4) Only applicable to Series B I/O modules.

Allen-Bradley MicroLogix 1100 Specifications

General

Processor	32-bit
Programming Software	RSLogix 500
Mounting	DIN rail or panel mount
Power Supply	24V DC
Type	Compact PLC
Digital Inputs	12
Digital Outputs	8
Analog Inputs	4 (depending on model)
Analog Outputs	Optional with expansion module
Programming Language	Ladder Logic
Operating Temperature	0 to 55 °C (32 to 131 °F)
Series	MicroLogix
