Allen-Bradley PanelView Plus 7 User Manual

Rockwell Automation Publication 2711P-UM007D-EN-P - December 2015 107
Windows Operating System Chapter 4
4. Transfer files between your computer and the FTP folder on the
terminal:
• Drag or copy a file from the FTP folder to your computer.
• Drag or copy a file to the FTP folder from your computer.
FTP Connection Requiring User Authentication
You can require a user name and password before establishing an FTP
connection. On the FTP Server tab, check Use Authentication. Select User
List and enter a valid user name in the field that opens at the bottom of tab.
To establish an FTP connection to the terminal by entering a valid user name
and password, follow these steps.
1. On your computer, open any folder or the browser.
2. Determine the IP address of your terminal by clicking the Network
Connection icon in the system tray.
3. Type the terminal IP address in the Windows Explorer address field.
4. Click OK if the FTP Folder Error dialog box appears.
5. From the File menu, choose Login As.
TIP User names and passwords are configured in the User Accounts
application of the control panel. Refer to User Accounts
on page 94 for
details.
EXAMPLE Use this syntax for the IP address:
ftp://ipaddress_of_the_terminal.
For example, ftp://192.168.124.96
TIP The user name must be in the User List of the FTP configuration
and previously configure as a valid account in the User Accounts
application.

Allen-Bradley PanelView Plus 7 Specifications

General

Operating System	Windows CE 6.0
Memory	512 MB RAM
Mounting	Panel mount
Display Type	Color TFT LCD
Processor	ARM Cortex-A8
Storage	512 MB Flash
Communication Ports	Ethernet, USB, Serial
Input Voltage	24V DC
Operating Temperature	0°C to 50°C (32°F to 122°F)
Environmental Rating	NEMA 4X
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Relative Humidity	5% to 95% non-condensing
Certifications	CE, UL, cUL
Display Sizes	4.3", 7", 10", 15", 19"
Touchscreen	Resistive or Projected Capacitive (depending on model)
