Allen-Bradley PanelView Plus 7 User Manual

Rockwell Automation Publication 2711P-UM007D-EN-P - December 2015 17
Overview Chapter 1
Accessories
Tabl e 4 through Table 9 list accessories for the PanelView Plus 7 Standard
terminals.
Table 4 - Protective Overlays
Cat. No. Display Size Touch Input Quantity
2711P-RGT4S 4.3-in. • 3
2711P-RGT6S 5.7-in. • 3
2711P-RGT7SP 6.5-in. • 3
2711P-RGT9SP 9.0-in. • 3
2711P-RGT10SP 10.4-in. • 3
2711P-RGT12SP 12.1-in. • 3
2711P-RGT15SP 15-in. • 3
Table 5 - Power Supplies and Power Terminal Blocks
Cat. No. Description Quantity
1606-XLP95E DIN-rail power supply, 24…28V DC output voltage, 95 W 1
1606-XLP100E DIN-rail power supply, 24…28V DC output voltage, 100 W 1
2711P-RSACDIN DIN-rail power supply, AC-to-DC, 85…265V AC, 47…63 Hz 1
2711P-RTBDSP 3-pin DC power terminal block (black with white labels for +, –, and GND) 10
Table 6 - Mounting Hardware
Cat. No. Description Quantity
2711P-RMCS
(1)
(1) Catalog number 2711P-RMCS mounting levers are for use only with PanelView Plus 7 Standard terminals. Do not use these
mounting levers with any other PanelView Plus terminals. Do not use black mounting levers; they are not compatible with
PanelView Plus 7 Standard terminals.
Mounting levers (gray) 12
Table 7 - SD Cards
(1)
(1) To reduce the chance of corruption when using SD Cards or USB drives with the terminal, Rockwell Automation recommends
that you use SD Card catalog numbers 1784-SD1 or 1784-SD2.
Cat. No. Description Quantity
1784-SD1 1-GB SD card 1
1784-SD2 2-GB SD card 1
2711C-RCSD USB to SD adapter for SD card 1
2711P-RCKS SD cover replacement 3
Table 8 - USB Programming Cable
Cat. No. Description Length
6189V-USBCBL2 Programming cable that connects the device port of the terminal to a
USB host port of a computer
1.8 m (5.9 ft)
