Rockwell Automation Publication 2711P-UM007D-EN-P - December 2015 25
Install the PanelView Plus 7 Standard Terminal Chapter 2
If cable capacitance and inductance are not known, use the following values
from ANSI/ISA-RP 12.06.01-2003:
C
cable
= 197 pF/m (60 pF/ft)
L
cable
= 0.7 µH/m (0.20 µH/ft)
Nonincendive field wiring must be wired and separated in accordance with
501.10(B)(3) of the National Electrical Code, ANSI/NFPA 70, or other local
codes as applicable. This associated nonincendive field wiring apparatus has
not been evaluated for use in combination with another associated
nonincendive field wiring apparatus.
Considerations for Mounting
Consider the following items when mounting the terminal:
• Typically, the terminal mounts on the vertical surface of a panel or
enclosure, at a 0° angle, just below eye level.
• Mount the terminal at a height suitable for most operators.
• Mount the terminal in an area that has good lighting.
• Do not mount the terminal where it is exposed to direct sunlight.
Clearances for Mounting
Plan for adequate space around the terminal and inside the enclosure for
ventilation and cables. Consider the heat produced by other devices in the
enclosure. The ambient temperature around the terminal must be 0…55 °C
(32…131 °F).
Table 12 - Minimum Required Clearances
Product Area Min Clearance
Top 51 mm (2 in.)
Bottom 51 mm (2 in.)
Side 25 mm (1 in.) on side without an SD card
51 mm (2 in.) on side with SD card
Back 0 mm (0 in.)
