Rockwell Automation Publication 2711P-UM007D-EN-P - December 2015 7
Summary of Changes
This manual contains new and updated information as indicated in the
following table.
Topic Page
Updated the illustrations to show two Ethernet ports on the Series B terminals with device
level ring (DLR) network functionality. Series B terminals are also available with a single
Ethernet port.
–
Added the EtherNet/IP Embedded Switch Technology Application Guide to the additional
resources table.
9
Added new UL, INMETRO, and EAC certifications to the overview. 12
Added new dual Ethernet port information to the hardware features table. 12
Added INMETRO to secure digital (SD) card usage information in hazardous locations. 12
Added the DLR designator ‘22’ to the catalog number explanation table. 16
Added new catalog numbers to the product selections table. 16
Added the INMETRO standards and ratings next to the ATEX ratings. 19
Added new UL ratings to the hazardous locations tables. 21, 22
Added Portuguese language content for the hazardous locations table for INMETRO. 23
Added information for new dual Ethernet ports. 36
Added a description and network diagram for a DLR network topology. 37
Updated the settings dialog box with the new Ethernet link speed options. 56
Updated the settings dialog box with the new Ethernet ports configuration options. 56
Removed the processor temperature display field from the terminal information screen. 70
Added system information screen with Ethernet port configuration information. 111
PanelView™ Plus 7 Standard Terminal
Series A and Series B with One Ethernet Port
PanelView Plus 7 Standard Terminal
Series B with Dual Ethernet Ports
