Allen-Bradley PanelView Plus 7 User Manual

Rockwell Automation Publication 2711P-UM007D-EN-P - December 2015 81
Windows Operating System Chapter 4
Server Support
Tabl e 21 lists the servers that support the Windows CE 6.0 operating system.
Table 21 - Windows CE 6.0 Server Support
Server
Default
State
Description
Web server Enabled The web server delivers content, such as web pages, by using the HTTP protocol
over the web.
FTP server Enabled File transfer protocol (FTP) is a standard network protocol that is used to
exchange files over the Internet (TCP/IP-based network).
UPnP server Enabled Universal plug and play (UPnP) is a set of networking protocols that lets devices
install and connect to a network.
File server Enabled A network protocol that provides shared access to files, printers, serial ports,
and miscellaneous communication between computers on a network.
VNC server Disabled Virtual network computing (VNC) is remote-control software that makes it
possible to control another computer over a network connection. Keystrokes
and mouse clicks are transmitted from one computer to another, over a
network.
ViewPoint
server
Enabled A web server application that provides remote users access via a web browser
to the FactoryTalk® View ME HMI application that is running on the terminal.
ViewPoint software is a Rockwell Automation® product.

Allen-Bradley PanelView Plus 7 Specifications

General

Operating System	Windows CE 6.0
Memory	512 MB RAM
Mounting	Panel mount
Display Type	Color TFT LCD
Processor	ARM Cortex-A8
Storage	512 MB Flash
Communication Ports	Ethernet, USB, Serial
Input Voltage	24V DC
Operating Temperature	0°C to 50°C (32°F to 122°F)
Environmental Rating	NEMA 4X
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Relative Humidity	5% to 95% non-condensing
Certifications	CE, UL, cUL
Display Sizes	4.3", 7", 10", 15", 19"
Touchscreen	Resistive or Projected Capacitive (depending on model)
