Allen-Bradley PowerFlex400 - Catalog Number Explanation

P-4 Overview
Catalog Number Explanation
Code Vol ta ge Ph.
B 240V AC 3
D 480V AC 3
Code Version
3 RS485
Code Interface Module
1 Fixed Keypad
Code Enclosure
N Panel Mount - IP20/UL Open-Type
(1)
A Panel Mount - IP30/NEMA 1/UL Type 1
(2)
F Flange Mount - IP20/UL Open Type
(3)
1-3 4 5 6-8 9 10 11 12
22C - D 038 A 1 0 3
Drive Dash Voltage Rating Rating Enclosure HIM Emission Class Comm Slot
Output Current @ 200-240V 60Hz Input
Code Amps kW (HP) Frame
012 12 2.2 (3.0) C
017 17.5 3.7 (5.0) C
024 24 5.5 (7.5) C
033 33 7.5 (10) C
049 49 11 (15) D
065 65 15 (20) D
075 75 18.5 (25) D
090 90 22 (30) D
120 120 30 (40) E
145 145 37 (50) E
Code Rating
0 Not Filtered
Output Current @ 380-480V Input
Code Amps kW (HP) Frame
6P0 6.0 2.2 (3.0) C
010 10.5 4.0 (5.0) C
012 12 5.5 (7.5) C
017 17 7.5 (10) C
022 22 11 (15) C
030 30 15 (20) C
038 38 18.5 (25) D
045 45.5 22 (30) D
060 60 30 (40) D
072 72 37 (50) E
088 88 45 (60) E
105 105 55 (75) E
142 142 75 (100) E
170 170 90 (125) F
208 208 110 (150) F
Code
22C PowerFlex 400
(1)
Frame C drives only available with IP20/UL Open-Type enclosure. Field installed conversion kit available
to achieve IP30/NEMA 1/UL Type 1 rating.
(2)
Frame D, E and F drives only available with IP30/NEMA 1/UL Type 1 enclosure.
(3)
Frame C drives only.
Additional accessories, options and adapters are available. See Appendix B for details.
