Allen-Bradley PowerFlex400 User Manual

P1 – Floor Level Network (FLN) G-3
a. Points not listed are not used in this application.
b. A single value in a column means that the value is the same in English units and in SI units.
c. Point numbers that appear in brackets { } may be unbundled at the field panel.
*1 Depends on drive model
*2 1 / Secs
*3 Depending on configuration, units can be volts or milliamperes.
*4 Local Control causes the drive to use C108
[Start Source 2] and C109 [Speed Ref 2] for start and
speed reference control.
65 LAO PID GAIN 1 PTC 0.01 0 – –
66 LAO PID INT TIME 2 SEC 0.1 0 – –
67 LAO PID DIF RATE 0 PERSEC *2 0.01 0 – –
68 LAO PID SETPOINT 0 PTC 0.1 0 – –
{70} LDI CMD DIR MON FWD – 1 0 REV FWD
{71} LDI ACCELERATING OFF – 1 0 ON OFF
{72} LDI DECELERATING OFF – 1 0 ON OFF
{73} LDI ALARM NORMAL – 1 0 ALARM NORMAL
{74} LDI AT SPEED OFF – 1 0 ON OFF
{75} LDI MAIN FREQ OFF – 1 0 ON OFF
{76} LDI OPER CMD OFF – 1 0 ON OFF
{77} LDI PARAM LOCK UNLOCK – 1 0 LOCK UNLOCK
{78} LDO JOG OFF – 1 0 ON OFF
{79} LDO LOCAL CNTRL *4 OFF– 10ONOFF
{80} LDO MOP INC OFF – 1 0 ON OFF
{81} LDO ACCEL RATE 1 OFF – 1 0 ON OFF
{82} LDO ACCEL RATE 2 OFF – 1 0 ON OFF
{83} LDO DECEL RATE 1 OFF – 1 0 ON OFF
{84} LDO DECEL RATE 2 OFF – 1 0 ON OFF
{85} LDO REF SELECT 1 OFF – 1 0 ON OFF
{86} LDO REF SELECT 2 OFF – 1 0 ON OFF
{87} LDO REF SELECT 3 OFF – 1 0 ON OFF
{88} LDO MOP DEC OFF – 1 0 ON OFF
{92} LAO REFERENCE 0 PCT 0.01 0 – –
{93} LDI OK.FAULT OK – 1 0 FAULT OK
{94} LDO RESET FAULT NORMAL – 1 0 RESET NORMAL
{99} LAO ERROR STATUS 0 – 1 0 – –
Table G.1 Point Database for Application 2735
Point
Number
Point
Type Subpoint Name
Factory
Default
(SI Units)
Engineering
Units
(SI Units)
Slope
(SI Units)
Intercept
(SI Units) On Text Off Text
