G-4 P1 – Floor Level Network (FLN)
Table G.2 Point Database for Application 2735
Point Number Subpoint Name Parameter
01 CTLR ADDRESS C104
02 APPLICATION –
03 FREQ OUTPUT b001
04 PCT OUTPUT d322
05 SPEED d323
06 CURRENT b003
07 TORQUE b013
08 POWER b010
09 DRIVE TEMP b014
11 DRIVE MWH b011
12 RUN TIME b012
13 DC BUS VOLT b005
20 OVRD TIME –
21 FWD.REV MON –
22 CMD FWD.REV –
23 RUN.STOP MON b066, bit 1 (Running)
24 CMD RUN.STOP –
25 READY d302, bit 2 (I/O Terminal 01)
26 RUN ENABLE –
29 DAY NGT –
30 CURRENT LIMIT P033
31 ACCEL TIME 1 P039
32 DECEL TIME 1 P040
33 KEYPAD LOCK A198
36 READ PARAM # –
37 READ VALUE –
38 WRITE PARAM # –
39 WRITE VALUE –
40 DIGITAL OUT 1 T055, T056
41 DIGITAL OUT 2 T060, T061
42 DIGITAL OUT 3 T065, T066
43 OPT RELAY 1 R221, R222 *1
44 OPT RELAY 2 R224, R225 *1
45 OPT RELAY 3 R227, R228 *1
46 OPT RELAY 4 R230, R231 *1
47 OPT RELAY 5 R233, R234 *1
48 OPT RELAY 6 R236, R237 *1
49 DIGITAL IN 1 d302, bit 0 (I/O Terminal 02)
50 DIGITAL IN 2 d302, bit 1 (I/O Terminal 03 )
51 DIGITAL IN 3 d302, bit 2 (I/O Terminal 01)
52 DIGITAL IN 4 d302, bit 3 (I/O Terminal 05)
53 DIGITAL IN 5 d302, bit 4 (I/O Terminal 06)
54 DIGITAL IN 6 d302, bit 5 (I/O Terminal 07)
55 DIGITAL IN 7 d302, bit 6 (I/O Terminal 08)
60 INPUT REF 1 d305
61 INPUT REF 2 d306
62 ANALOG OUT 1 T082
63 ANALOG OUT 2 T085
64 LAST FAULT b007
65 PID GAIN A154
66 PID INT TIME A155
67 PID DIFF RATE A156
68 PID SETPOINT A157
