Allen-Bradley PowerFlex400

Accessories and Dimensions B-7
Table B.13 PowerFlex 400 Frames and Weights
Product Dimensions
Frame kW (HP)
Drive Weight
kg (lbs.)
Packaged Weight
kg (lbs.)
240V AC – 3-Phase
C 2.2 (3.0) 2.89 (6.4) 3.41 (7.5)
C 4.0 (5.0) 2.97 (6.5) 3.49 (7.7)
C 5.5 (7.5) 3.72 (8.2) 4.27 (9.4)
C 7.5 (10) 3.78 (8.3) 4.33 (9.5)
D 11 (15) 12.1 (26.7) 13.4 (29.5)
D 15 (20) 12.7 (28.0) 14 (30.9)
D 18.5 (25) 12.7 (28.0) 14 (30.9)
D 22 (30) 12.7 (28.0) 14 (30.9)
E 30 (40) 38 (83.8) 48.2 (106.3)
E 37 (50) 38 (83.8) 48.2 (106.3)
480V AC – 3-Phase
C 2.2 (3.0) 2.87 (6.3) 3.39 (7.5)
C 4.0 (5.0) 3.03 (6.7) 3.55 (7.8)
C 5.5 (7.5) 3.65 (8.0) 4.2 (9.3)
C 7.5 (10) 3.75 (8.3) 4.3 (9.5)
C 11 (15) 6.41 (14.1) 7.41 (16.3)
C 15 (20) 6.47 (14.3) 7.49 (16.5)
D 18.5 (25) 12.7 (28.0) 14 (30.9)
D 22 (30) 12.7 (28.0) 14 (30.9)
D 30 (40) 14.3 (31.5) 15.6 (34.4)
E 37 (50) 36 (79.4) 46.2 (101.9)
E 45 (60) 36 (79.4) 46.2 (101.9)
E 55 (75) 41 (90.4) 51.2 (112.9)
E 75 (100) 41 (90.4) 51.2 (112.9)
F 90 (125) 78 (172.0) 88 (194.0)
F 110 (150) 78 (172.0) 88 (194.0)
240V AC – 3-Phase, Plate Drive
C 2.2 (3.0) 2.66 (5.9) 3.26 (7.2)
C 4.0 (5.0) 2.74 (6.0) 3.34 (7.4)
C 5.5 (7.5) 3.15 (6.9) 3.75 (8.3)
C 7.5 (10) 3.21 (7.1) 3.81 (8.4)
480V AC – 3-Phase, Plate Drive
C 2.2 (3.0) 2.63 (5.8) 3.23 (7.1)
C 4.0 (5.0) 2.77 (6.1) 3.37 (7.4)
C 5.5 (7.5) 3.04 (6.7) 3.64 (8.0)
C 7.5 (10) 3.13 (6.9) 3.73 (8.2)
C 11 (15) 3.19 (7.0) 3.79 (8.4)
C 15 (20) 3.25 (7.2) 3.85 (8.5)
