B-2 Accessories and Dimensions
Table B.3 PowerFlex 400 Flange Mount Drives
Table B.4 Bulletin 1321-3R Series Line Reactors – 200-240V, 60 Hz, Three-Phase
Drive Ratings
Catalog Number
Frame
SizeInput Voltage kW HP
Output Current
45°C 50°C
240V 50/60 Hz
3-Phase
2.2 3 12A 12A 22C-B012F103 C
3.7 5 17.5A 17.5A 22C-B017F103 C
5.5 7.5 24A 24A 22C-B024F103 C
7.5 10 33A 33A 22C-B033F103 C
480V 50/60 Hz
3-Phase
2.2 3 6.0A 6.0A 22C-D6P0F103 C
4.0 5 10A 10A 22C-D010F103 C
5.5 7.5 12A 12A 22C-D012F103 C
7.5 10 17A 17A 22C-D017F103 C
11 15 22A 22A 22C-D022F103
(1)
(1)
A DC bus inductor is required. See Ta b l e B . 7 for ordering information.
C
15 20 30A 27A 22C-D030F103
(1)
C
kW HP
Fundamental
Amps
Maximum
Continuous
Amps
Inductance
mh
Watts
Loss
Catalog Number
IP00
(Open Style)
IP11
(MENA Type 1)
3% Impedance
2.2 3.0 12 18 1.25 26 1321-3R12-A 1321-3RA12-A
3.7 5.0 18 27 0.8 36 1321-3R18-A 1321-3RA18-A
5.5 7.5 25 37.5 0.5 48 1321-3R25-A 1321-3RA25-A
7.5 10 35 52.5 0.4 49 1321-3R35-A 1321-3RA35-A
11 15 45 67.5 0.3 54 1321-3R45-A 1321-3RA45-A
15 20 55 82.5 0.25 64 1321-3R55-A 1321-3RA55-A
18.5 25 80 120 0.2 82 1321-3R80-A 1321-3RA80-A
22 30 80 120 0.2 82 1321-3R80-A 1321-3RA80-A
30 40 100 150 0.15 94 1321-3R100-A 1321-3RA100-A
37 50 130 195 0.1 108 1321-3R130-A 1321-3RA130-A
5% Impedance
2.2 3.0 12 18 2.5 31 1321-3R12-B 1321-3RA12-B
3.7 5.0 18 27 1.5 43 1321-3R18-B 1321-3RA18-B
5.5 7.5 25 37.5 1.2 52 1321-3R25-B 1321-3RA25-B
7.5 10 35 52.5 0.8 54 1321-3R35-B 1321-3RA35-B
11 15 45 67.5 0.7 62 1321-3R45-B 1321-3RA45-B
15 20 55 82.5 0.5 67 1321-3R55-B 1321-3RA55-B
18.5 25 80 120 0.4 86 1321-3R80-B 1321-3RA80-B
22 30 80 120 0.4 86 1321-3R80-B 1321-3RA80-B
30 40 100 150 0.3 84 1321-3R100-B 1321-3RA100-B
37 50 130 195 0.2 180 1321-3R130-B 1321-3RA130-B
