Accessories and Dimensions B-5
Table B.9 Communication Option Kits and Accessories
Item Description Catalog Number
DeviceNet
Communication Adapter
Embedded communication option for use with the
PowerFlex family of drives.
Requires a Communication Adapter Cover when
used with Frame C PowerFlex 400 drives (Ordered
Separately).
22-COMM-D
EtherNet/IP
Communication Adapter
Embedded communication option for use with the
PowerFlex family of drives.
Requires a Communication Adapter Cover when
used with Frame C PowerFlex 400 drives (Ordered
Separately).
22-COMM-E
Profibus DP
Communication Adapter
Embedded communication option for use with the
PowerFlex family of drives.
Requires a Communication Adapter Cover when
used with Frame C PowerFlex 400 drives (Ordered
Separately).
22-COMM-P
Communication Adapter
Cover
Cover that houses the communication adapter.
Frame C Drive 22C-CCC
Serial Converter Module
(RS485 to RS232)
Provides serial communication via DF1 protocol for
use with DriveExplorer and DriveExecutive software.
Includes:
DSI to RS232 serial converter (one)
1203-SFC serial cable (one)
22-RJ45CBL-C20 cable (one)
DriveExplorer Lite CD (one)
22-SCM-232
DSI Cable 2.0 meter RJ45 to RJ45 cable, male to male
connectors.
22-RJ45CBL-C20
Serial Cable 2.0 meter serial cable with a locking low profile
connector to connect to the serial converter and a
9-pin sub-miniature D female connector to connect to
a computer.
1203-SFC
Null Cable Converter For use when connecting the serial converter to
DriveExplorer on a handheld PC.
1203-SNM
Splitter Cable RJ45 one to two port splitter cable AK-U0-RJ45-SC1
Terminating Resistors RJ45 120 Ohm resistors (2 pieces) AK-U0-RJ45-TR1
Terminal Block RJ45 Two position terminal block (5 pieces) AK-U0-RJ45-TB2P
DriveExplorer Software
(CD-ROM) Version 3.01
or later
Windows based software package that provides an
intuitive means for monitoring or configuring
Allen-Bradley drives and communication adapters
online.
Compatibility:
Windows 95, 98, ME, NT 4.0 (Service Pack 3 or
later), 2000, XP and CE
(1)
(1)
See www.ab.com/drives/driveexplorer.htm for supported devices.
9306-4EXP01ENE
DriveExecutive software
(CD-ROM) Version 1.01
or later
Windows based software package that provides an
intuitive means for monitoring or configuring
Allen-Bradley drives and communication adapters
online and offline.
Compatibility:
Windows 98, ME, NT 4.0 (Service Pack 3 or later),
2000 and XP
9303-4DTE01ENE
Serial Flash Firmware
Kit
Use a PC to update drive firmware. AK-U9-FLSH1
