Accessories and Dimensions B-3
Table B.5 Bulletin 1321-3R Series Line Reactors – 380-480V, 60 Hz, Three-Phase
Table B.6 Bulletin 1321 - DC Series Bus Inductors - 200-240V, 60 Hz, Three-Phase
kW HP
Fundamental
Amps
Maximum
Continuous
Amps Inductance
Watts
Loss
Catalog Number
IP00
(Open Style)
IP11
(MENA Type 1)
3% Impedance
2.2 3.0 8 12 5 25.3 1321-3R8-C 1321-3RA8-C
4.0 5.0 12 18 2.5 31 1321-3R12-B 1321-3RA12-B
5.5 7.5 12 18 2.5 31 1321-3R12-B 1321-3RA12-B
7.5 10 18 27 1.5 43 1321-3R18-B 1321-3RA18-B
11 15 25 37.5 1.2 52 1321-3R25-B 1321-3RA25-B
15 20 35 52.5 0.8 54 1321-3R35-B 1321-3RA35-B
18.5 25 35 52.5 0.8 54 1321-3R35-B 1321-3RA35-B
22 30 45 67.5 0.7 62 1321-3R45-B 1321-3RA45-B
30 40 55 82.5 0.5 67 1321-3R55-B 1321-3RA55-B
37 50 80 120 0.4 86 1321-3R80-B 1321-3RA80-B
45 60 80 120 0.4 86 1321-3R80-B 1321-3RA80-B
55 75 100 150 0.3 84 1321-3R100-B 1321-3RA100-B
75 100 130 195 0.2 180 1321-3R130-B 1321-3RA130-B
90 125 160 240 0.15 149 1321-3R160-B 1321-3RA160-B
110 150 200 300 0.11 168 1321-3R200-B 1321-3RA200-B
5% Impedance
2.2 3.0 8 12 7.5 28 1321-3R8-D 1321-3RA8-D
4.0 5.0 12 18 4.2 41 1321-3R12-C 1321-3RA12-C
5.5 7.5 12 18 4.2 41 1321-3R12-C 1321-3RA12-C
7.5 10 18 27 2.5 43 1321-3R18-C 1321-3RA18-C
11 15 25 37.5 2.0 61 1321-3R25-C 1321-3RA25-C
15 20 35 52.5 1.2 54 1321-3R35-C 1321-3RA35-C
18.5 25 35 52.5 1.2 54 1321-3R35-C 1321-3RA35-C
22 30 45 67.5 1.2 65 1321-3R45-C 1321-3RA45-C
30 40 55 82.5 0.85 71 1321-3R55-C 1321-3RA550-C
37 50 80 120 0.7 96 1321-3R80-C 1321-3RA80-C
45 60 80 120 0.7 96 1321-3R80-C 1321-3RA80-C
55 75 100 150 0.45 108 1321-3R100-C 1321-3RA100-C
75 100 130 195 0.3 128 1321-3R130-C 1321-3RA130-C
90 125 160 240 0.23 138 1321-3R160-C 1321-3RA160-C
110 150 200 300 0.185 146 1321-3R200-C 1321-3RA200-C
kW HP DC Amps
Inductance
mh Watts Loss
Catalog Number
IP00 (Open Style)
2.2 3 12 0.92 5 1321-DC12-1
3.7 5 18 0.63 5 1321-DC18-1
5.5 7.5 32 0.85 11 1321-DC32-1
7.5 10 40 0.75 15 1321-DC40-2
