1-16 Installation/Wiring
Important points to remember about I/O wiring:
• Always use copper wire.
• Wire with an insulation rating of 600V or greater is recommended.
• Control and signal wires should be separated from power wires by at
least 0.3 meters (1 foot).
Control Wire Types
Table 1.E Recommended Control and Signal Wire
(1)
I/O Terminal Block
Table 1.F I/O Terminal Block Specifications
(2)
Maximum/minimum sizes that the terminal block will accept - these are not
recommendations.
Maximum Control Wire Recommendations
Do not exceed control wiring length of 30 meters (100 feet). Control
signal cable length is highly dependent on electrical environment and
installation practices. To improve noise immunity, the I/O terminal block
Common must be connected to ground terminal/protective earth. If using
the RS485 (DSI) port, I/O Terminal 20 should also be connected to
ground terminal/protective earth.
!
ATTENTION: Driving the 4-20mA analog input from a voltage
source could cause component damage. Verify proper configuration
prior to applying input signals.
Wire Type(s) Description Minimum
Insulation Rating
Belden 8760/9460
(or equiv.)
0.8 mm
2
(18AWG), twisted pair, 100%
shield with drain.
(1)
(1)
If the wires are short and contained within a cabinet which has no sensitive circuits,
the use of shielded wire may not be necessary, but is always recommended.
300V
60 degrees C
(140 degrees F)
Belden 8770
(or equiv.)
0.8 mm
2
(18AWG), 3 conductor, shielded for
remote pot only.
Frame Maximum Wire Size
(2)
Minimum Wire Size
(2)
Torque
C, D, E, F 1.3 mm
2
(16 AWG) 0.13 mm
2
(26 AWG) 0.5-0.8 N-m (4.4-7 lb.-in.)
