Allen-Bradley PowerFlex400 User Manual

Appendix B
Accessories and Dimensions
Table B.1 Catalog Number Description
Table B.2 PowerFlex 400 Drives
Product Selection
22C - B 024 N 1 0 3
Drive Voltage Rating Rating Enclosure HIM Emission Class Comm Slot
Drive Ratings
Catalog Number
Frame
SizeInput Voltage kW HP
Output Current
(Amps)
45°C 50°C
240V 50/60 Hz
3-Phase
2.2 3.0 12 12 22C-B012N103 C
3.7 5.0 17.5 17.5 22C-B017N103 C
5.5 7.5 24 24 22C-B024N103 C
7.5 10 33 33 22C-B033N103 C
11 15 49 49 22C-B049A103 D
15 20 65 65 22C-B065A103 D
18.5 25 75 75 22C-B075A103 D
22 30 90 81 22C-B090A103 D
30 40 120 120 22C-B120A103 E
37 50 145 130 22C-B145A103 E
480V 50/60 Hz
3-Phase
2.2 3.0 6 6 22C-D6P0N103 C
4.0 5.0 10.5 10.5 22C-D010N103 C
5.5 7.5 12 12 22C-D012N103 C
7.5 10 17 17 22C-D017N103 C
11 15 22 22 22C-D022N103 C
15 20 30 27 22C-D030N103 C
18.5 25 38 38 22C-D038A103 D
22 30 45.5 45.5 22C-D045A103 D
30 40 60 54 22C-D060A103 D
37 50 72 72 22C-D072A103 E
45 60 88 88 22C-D088A103 E
55 75 105 105 22C-D105A103 E
75 100 142 128 22C-D142A103 E
90 125 170 170 22C-D170A103 F
110 150 208 208 22C-D208A103 F
