F-4 Metasys N2
Table F.9 Binary Outputs
Network Point
Name Description
Values
Type
(NPT)
Address
(NPA) ON (“1”) OFF (“0”)
BO 1 Run Enable Logic Command bit 00 Enable Stop (Coast)
BO 2 Start/Stop Logic Command bit 00 & 01 Start Stop (Normal)
BO 3 Jog Logic Command bit 02 Jog Not Jog
BO 4 Clear Faults Logic Command bit 03 Clear Flts Not Clear Flts
BO 5 Fwd/Rev Logic Command bit 04 & 05 Forward Reverse
BO 6 Not Used Logic Command bit 06 – –
BO 7 MOP Inc Logic Command bit 07 Increment Not Increment
BO 8 Accel 1 Logic Command bit 08 Accel Rate 1 Not Accel 1
BO 9 Accel 2 Logic Command bit 09 Accel Rate 2 Not Accel 2
BO 10 Decel 1 Logic Command bit 10 Decel Rate 1 Not Decel 1
BO 11 Decel 2 Logic Command bit 11 Decel Rate 2 Not Decel 2
BO 12 Ref Sel 1 Logic Command bit 12 BO
BO 13 Ref Sel 2 Logic Command bit 13 14 13 12
BO 14 Ref Sel 3 Logic Command bit 14 000=No Command
001= P038 [Speed Reference]
010=A142 [Internal Freq]
011=Comm - Address 8193
(1)
100=A143 [Preset Freq 0]
101=A144 [Preset Freq 1]
110=A145 [Preset Freq 2]
111=A146 [Preset Freq 3]
BO 15 MOP Dec Logic Command bit 15 Decrement Not Decrement
BO 16 Pnl Lock Lock-out Drive Front Panel Lock Unlock
BO 17 Digital Out 1 Relay #1 on Drive
(Drive Terminal R1, R2, R3)
On Off
BO 18 Digital Out 2 Relay #2 on Drive
(Drive Terminal R4, R5, R6)
On Off
BO 19 Opto Out Terminal #19 On Off
(1)
See Writing (06) Reference on page E-3.
Table F.10 Analog Outputs
Network Point
Name Description Units Min/Max
Type
(NPT)
Address
(NPA)
AO 1 Reference Reference % 0/100
AO 2 Accel 1 P039 [Accel Time 1] Secs 0.0/600.0
AO 3 Decel 1 P040 [Decel Time 1] Secs 0.0/600.0
AO 4 Mtr OL Current P033 [Motor OL Current] A 0.0/Rated × 2
AO 5 PID Setpoint A157 [PID Setpoint] % 0/100
AO 6 Analog Out 1 Drive Analog Output #1 (T084) % –
AO 7 Analog Out 2 Drive Analog output #2 (T087) % –
AO 8 Write Param # Param. number to write in AO 9 – 0 to Max Param.
AO 9 Write Value Write value of param. selected by AO 8 Based on AO 8 selected param.
AO 10 Read Param # Param. number to read in AI 9 – 0 to Max Param.
AO 11 User Out 1 User-defined Output 1
(Param. selected via ADI 5)
Varies by the parameter
selected.
AO 12 User Out 2 User-defined Output 2
(Param. selected via ADI 6)
AO 13 User Out 3 User-defined Output 3
(Param. selected via ADI 7)
AO 14 User Out 4 User-defined Output 4
(Param. selected via ADI 8)
