3-14 Programming and Parameters
Terminal Block Group (continued)
T055 [Relay Out1 Sel] Related Parameter(s): P033, T056, T058, T059, T069
T072, T073, T076, A163, d318
Sets the condition that changes the state of the output relay contacts.
Options 0 “Ready/Fault”
(Default)
Relay changes state when power is applied. This indicates
that the drive is ready for operation. Relay returns drive to
shelf state when power is removed or a fault occurs.
1 “At Frequency” Drive reaches commanded frequency.
2 “MotorRunning Motor is receiving power from the drive.
3 “Hand Active” Active when drive is in local control.
4 “Motor Overld” Motor overload condition exists.
5 “Ramp Reg” Ramp regulator is modifying the programmed accel/decel
times to avoid an overcurrent or overvoltage fault from
occurring.
6 “Above Freq” Drive exceeds the frequency (Hz) value set in T056
[Relay
Out1 Level].
Use T056 to set threshold.
7 “Above Cur” Drive exceeds the current (% Amps) value set in T056
[Relay Out1 Level].
Use T056 to set threshold.
Important: Value for T056 [Relay Out1 Level] must be
entered in percent of drive rated output current.
8 “Above DCVolt” Drive exceeds the DC bus voltage value set in T056
[Relay Out1 Level].
Use T056 to set threshold.
9 “Above Anlg 2” Analog input voltage (I/O Terminal 17) exceeds the value
set in T056
[Relay Out1 Level].
Do not use if T073
[Analog In 2 Sel] is set to 3 “Voltage
Mode - Bipolar”.
This parameter setting can also be used to indicate a PTC
trip point when the input (I/O Terminal 17) is wired to a
PTC and external resistor.
Use T056 to set threshold.
10 “Above PF Ang” Power Factor angle has exceeded the value set in T056
[Relay Out1 Level].
Use T056 to set threshold.
11 “Anlg In Loss” Analog input loss has occurred. Program T072
[Analog In 1
Loss] and/or T076
[Analog In 2 Loss] for desired action when
input loss occurs.
12 “ParamControl” Enables the output to be controlled over network
communications by writing to T056
[Relay Out1 Level].
(0 = Off, 1 = On.)
13 “Retries Exst” Value set in A163
[Auto Rstrt Tries] is exceeded.
14 “NonRec Fault” Number of retries for [Restart Tries] is exceeded
OR
Non-resettable fault occurs
OR
Auto-retries is not enabled.
15 “Reverse” Drive is commanded to run in reverse direction.
16 “Logic In 1” An input is programmed as “Logic In 1” and is active.
17 “Logic In 2” An input is programmed as “Logic In 2” and is active.
23 “Aux Motor” Auxiliary Motor is commanded to run. Refer to Appendix
C for
details.
