3-4 Programming and Parameters
Basic Display Group
b001 [Output Freq] Related Parameter(s): b002, b008, P034, P035, P038
Output frequency present at T1, T2 & T3 (U, V & W).
Values Default: Read Only
Min/Max: 0.00/P035
[Maximum Freq]
Display: 0.01 Hz
b002 [Commanded Freq] Related Parameter(s): b001, P034, P035, P038, d302
Value of the active frequency command. Displays the commanded frequency even if the drive is not
running.
Important: The frequency command can come from a number of sources. Refer to Start and Speed
Reference Control on page 1-24 for details.
Values Default: Read Only
Min/Max: 0.00/P035
[Maximum Freq]
Display: 0.01 Hz
b003 [Output Current]
The output current present at T1, T2 & T3 (U, V & W).
Values Default: Read Only
Min/Max: 0.0/(Drive Rated Amps × 2)
Display: 0.1 Amps
b004 [Output Voltage] Related Parameter(s): P031, A170, A174
Output voltage present at terminals T1, T2 & T3 (U, V & W).
Values Default: Read Only
Min/Max: 0/510
Display: 1 VAC
b005 [DC Bus Voltage]
Present DC bus voltage level.
Values Default: Read Only
Min/Max: 0/820
Display: 1 VDC
