Page #68 background imageLoading...
Page #68 background image
3-16 Programming and Parameters
Terminal Block Group (continued)
T060 [Relay Out2 Sel] Related Parameter(s): P033, T061, T063, T064, T076
A163, d318
Sets the condition that changes the state of the output relay contacts.
Options 0 “Ready/Fault” Relay changes state when power is applied. This indicates
that the drive is ready for operation. Relay returns drive to
shelf state when power is removed or a fault occurs.
1 “At Frequency” Drive reaches commanded frequency.
2 “MotorRunning”
(Default)
Motor is receiving power from the drive.
3 “Hand Active” Active when drive is in local control.
4 “Motor Overld” Motor overload condition exists.
5 “Ramp Reg” Ramp regulator is modifying the programmed accel/decel
times to avoid an overcurrent or overvoltage fault from
occurring.
6 “Above Freq” Drive exceeds the frequency (Hz) value set in T061
[Relay
Out2 Level].
Use T061 to set threshold.
7 “Above Cur” Drive exceeds the current (% Amps) value set in T061
[Relay Out2 Level].
Use A061 to set threshold.
Important: Value for T061 [Relay Out2 Level] must be
entered in percent of drive rated output current.
8 “Above DCVolt” Drive exceeds the DC bus voltage value set in T061
[Relay Out2 Level].
Use T061 to set threshold.
9 “Above Anlg 2” Analog input voltage (I/O Terminal 17) exceeds the value
set in T061
[Relay Out2 Level].
Do not use if T073
[Analog In 2 Sel] is set to 3 “Voltage
Mode - Bipolar”.
This parameter setting can also be used to indicate a PTC
trip point when the input (I/O Terminal 17) is wired to a
PTC and external resistor.
Use T061 to set threshold.
10 “Above PF Ang” Power Factor angle has exceeded the value set in T061
[Relay Out2 Level].
Use T061 to set threshold.
11 “Anlg In Loss” Analog input loss has occurred. Program T072
[Analog In 1
Loss] and/or T076 [Analog In 2 Loss] for desired action when
input loss occurs.
12 “ParamControl” Enables the output to be controlled over network
communications by writing to T061
[Relay Out2 Level].
(0 = Off, 1 = On.)
13 “Retries Exst” Value set in A163
[Auto Rstrt Tries] is exceeded.
14 “NonRec Fault” Number of retries for A163
[Auto Rstrt Tries] is exceeded
OR
Non-resettable fault occurs
OR
A163
[Auto Rstrt Tries] is not enabled.
15 “Reverse” Drive is commanded to run in reverse direction.
16 “Logic In 1” An input is programmed as “Logic In 1” and is active.
17 “Logic In 2” An input is programmed as “Logic In 2” and is active.
23 “Aux Motor” Auxiliary Motor is commanded to run. Refer to Appendix
C for
details.
