Allen-Bradley PowerFlex400 User Manual

G-2 P1 – Floor Level Network (FLN)
Network Points
Table G.1 Point Database for Application 2735
Point
Number
Point
Type Subpoint Name
Factory
Default
(SI Units)
Engineering
Units
(SI Units)
Slope
(SI Units)
Intercept
(SI Units) On Text Off Text
01 LAO CTLR ADDRESS 99 – 1 0 – –
02 LAO APPLICATION 2735 – 1 0 – –
{03} LAI FREQ OUTPUT 0 HZ 0.01 0 – –
{04} LAI PCT OUTPUT 0 PCT 0.1 0 – –
{05} LAI SPEED 0 RPM 1 0 – –
{06} LAI CURRENT 0 AMPS 0.1 0 – –
{07} LAI TORQUE 0 AMPS 0.1 0 – –
{08} LAI POWER 0 HP
(KW)
0.1333
(0.1)
0
(0)
––
{09} LAI DRIVE TEMP 0 DEG F
(DEG C)
1.8
(1)
32
(0)
––
{11} LAI DRIVE MWH 0 MWH 0.1 0 – –
{12} LAI RUN TIME 0 HRS 10 0 – –
{13} LAI DC BUS VOLT 0 VOLTS 1 0 – –
20 LAO OVRD TIME 1 HRS 1 0 – –
{21} LDI FWD.REV MON FWD – 1 0 REV FWD
{22} LDO CMD FWD.REV FWD – 1 0 REV FWD
{23} LDI RUN.STOP MON STOP – 1 0 RUN STOP
{24} LDO CMD RUN.STOP STOP – 1 0 RUN STOP
{25} LDI READY READY – 1 0 READY NOTRDY
{26} LDO RUN ENABLE STOP – 1 0 ENABLE STOP
{29} LDO DAY NGT DAY – 1 0 NIGHT DAY
30 LAO CURRENT LIMT *1 AMPS 0.1 0 – –
31 LAO ACCEL TIME 20 SEC 0.02 0 – –
32 LAO DECEL TIME 20 SEC 0.02 0 – –
33 LDO KEYPAD LOCK UNLOCK – 1 0 LOCK UNLOCK
{36} LAO READ PARAM 0 – 1 0 – –
{37} LAI READ VALUE 0 – 1 0 – –
{38} LAO WRITE PARAM 0 – 1 0 – –
{39} LAO WRITE VALUE 0 – 1 0 – –
{40} LDO DIGITAL OUT1 OFF – 1 0 ON OFF
{41} LDO DIGITAL OUT2 OFF – 1 0 ON OFF
{42} LDO DIGITAL OUT3 OFF – 1 0 ON OFF
{43} LDO OPT RELAY 1 OFF – 1 0 ON OFF
{44} LDO OPT RELAY 2 OFF – 1 0 ON OFF
{45} LDO OPT RELAY 3 OFF – 1 0 ON OFF
{46} LDO OPT RELAY 4 OFF – 1 0 ON OFF
{47} LDO OPT RELAY 5 OFF – 1 0 ON OFF
{48} LDO OPT RELAY 6 OFF – 1 0 ON OFF
{49} LDI DIGITAL IN 1 OFF – 1 0 ON OFF
{50} LDI DIGITAL IN 2 OFF – 1 0 ON OFF
{51} LDI DIGITAL IN 3 OFF – 1 0 ON OFF
{52} LDI DIGITAL IN 4 OFF – 1 0 ON OFF
{53} LDI DIGITAL IN 5 OFF – 1 0 ON OFF
{54} LDI DIGITAL IN 6 OFF – 1 0 ON OFF
{55} LDI DIGITAL IN 7 OFF – 1 0 ON OFF
{60} LAI INPUT REF 1 0 *3 0.1 0 – –
{61} LAI INPUT REF 2 0 *3 0.1 0 – –
{62} LAO ANALOG OUT 1 0 PCT 0.1 0 – –
{63} LAO ANALOG OUT 2 0 PCT 0.1 0 – –
{64} LAI LAST FAULT 0 – 1 0 – –
