Allen-Bradley SLC 500

Index
I–2
Publication 1747-6.2
hardware features, 5-2, 6-1
LEDs, 5-3
troubleshooting, 10-3
5/02 processors
general specifications, 2-9
hardware features, 5-4
installing, 6-1
LEDs, 5-4
troubleshooting, 10-3
5/03 processor
active modem-control lines
CTS (Clear to Send), B-7
DCD (Data Carrier Detect), B-7
DSR (Data Set Ready), B-7
DTR (Data T erminal Ready), B-7
R TS (Request to Send), B-7
DF1 full-duplex protocol, B-2
DF1 half-duplex protocol, B-2
general specifications, 2-9
hardware features, 5-6
installing, 6-1
keyswitch, 5-15
LEDs, 5-8
operating system memory module
installation, 6-4
returning processor to “initial factory
conditions”, 10-25
troubleshooting, 10-1 1
5/04 processors
active modem-control lines
CTS (Clear to Send), B-7
DCD (Data Carrier Detect), B-7
DSR (Data Set Ready), B-7
DTR (Data T erminal Ready), B-7
R TS (Request to Send), B-7
channel 0, RS-232 communication, C-2
DF1 full-duplex protocol, B-2
DF1 half-duplex protocol, B-2
general specifications, 2-9
hardware features, 5-9
installing, 6-1
keyswitch, 5-15
LEDs, 5-1 1, 5-14
operating system memory module
installation, 6-4
returning processor to “initial factory
conditions”, 10-25
troubleshooting, 10-1 1
5/05 processor, general specifications, 2-9
5/05 processors
hardware features, 5-12, 5-13
installing, 6-1
operating system memory module
installation, 6-4
returning processor to ”initial factory
conditions”, 10-25
troubleshooting, 10-1 1
6001-6.5.5, publication number , A-3
A
adapter socket
for the SLC 5/01 or SLC 5/02 processors,
2-19
for the SLC 5/03 and higher processors,
2-20
AIC+ Advanced Interface Converter ,
mounting dimensions, 4-6
Allen-Bradley , contacting for assistance, P-4
ambient operating temperature rating, for
power supplies, 2-1 1
ambient temperature rating, processor
specification, 2-9
Article 70B of the NFP A, 3-12
Article 70E of the NFP A, 3-1
ASCII communication, B-7
B
BASIC programming language, B-3
batteries, lithium
Code of Federal Regulations, 49 CFR
173.22a, 9-2
DOT -E7052 provision, 9-2
shipping when depleted, 9-2
storing and handling, 9-1
transportation, 9-2
battery , installation
SLC 5/01 or SLC 5/02 processors, 9-4
SLC 5/03 and higher processors, 9-5
Belden #3106A, terminal connections, A-12
Belden #9463, C-3
Belden #9842
on the DH-485 network, A-10
wire/terminal connections, A-13
bit execution, processor specification, 2-9
boot-server host, G-6
BOOTP
edit configuration file, G-7
example, G-8
hardware address, G-8
install, G-7
IP address, G-8
