Rockwell Automation Publication 1560F-UM001A-EN-P - June 2019 227
Parameter Information Appendix A
309 Input Status 0/65535 0
Input 1
Input 2
Input 7-1
Input 7-2
Input 7-3
Input 7-4
Input 8-1
Input 8-2
Input 8-3
Input 8-4
Input 9-1
Input 9-2
Input 9-3
Input 9-4
Displays the status of all the digital inputs for the SMC-50
Bit 0
- Displays status of control module input #1;
Bit 1
- Displays status of Control Module Input #2.
Bit 2 - Displays status of Control Module Port 7, 150-SM4
Option Module Input #1.
Bit 3
- Displays status of Control Module Port 7, 150-SM4
Option Module Input #2.
Bit 4- Displays status of Control Module Port 7, 150-SM4 Option
Module Input #3.
Bit 5- Displays status of Control Module Port 7, 150-SM4 Option
Module Input #4.
Bit 6
- Displays status of Control Module Port 8, 150-SM4
Option Module Input #1.
Bit 7- Displays status of Control Module Port 8, 150-SM4 Option
Module Input #2.
Bit 8- Displays status of Control Module Port 8, 150-SM4 Option
Module Input #3.
Bit 9
- Displays status of Control Module Port 8, 150-SM4 Option
Module Input #4.
Bit 10 - Displays status of Control Module Port 9, 150-SM4
Option Module Input #1.
Bit 11 - Displays status of Control Module Port 9, 150-SM4
Option Module Input #2.
Bit 12
- Displays status of Control Module Port 9, 150-SM4
Option Module Input #3.
Bit 13 - Displays status of Control Module Port 9, 150-SM4
Option Module Input #4.
Bit 14 & 15 - Reserved.
R
310 Locked Rotor A Lvl %FLC 400/1000 600 Enables the user to enter a value for the Locked Rotor Alarm
Level (Locked Rtr A Lvl). The locked rotor value represents the
motor peak phase current to the load that if exceeded for the
period defined in Locked Rtr A Delay will signal a fault. The
Locked Rotor bit in the Motor Alarm En parameter must be set
to signal a alarm.
R/W
311 Locked Rotor A Dly Secs 0.1/100 0.1 The time period that the peak phase current exceeds the Locked
Rtr F Level to signal a fault. The Locked Rotor bit in the Motor
Fault En parameter must be set to enable a fault.
R/W
