Parameter Information Appendix A
348 Ref Source 0/8
[Output V Ref ]
P7 In1
P7 In2
P8 In1
P8 In2
P9 In1
P9 In2
DLX Output 1
DLX Output 2
Allows selection of Source for Resistive Heater Output Voltage
-Output Voltage Reference Parameter (Set in Par349)
-Analog Input #1 from 150-SM3 option module in Expansion
Port 7
-Analog Input #2 from 150-SM3 option module in Expansion
Port 7
-Analog Input #1 from 150-SM3 option module in Expansion
Port 8
-Analog Input #2 from 150-SM3 option module in Expansion
Port 8
-Analog Input #1 from 150-SM3 option module in Expansion
Port 9
-Analog Input #2 from 150-SM3 option module in Expansion
Port 9
-DeviceLogix Output #1
-DeviceLogix Output #2
R/W
349 Output V Ref % 1/100 1 N/A Parameter that can be set from 1% to 100% output voltage for
Resistive Heating Mode.
R/W
351 OverCurrent LVL % 800/1000 800 Threshold for overcurrent protection (the manually enabled
one)
R/W
Table 66 - SMC -50 Parameter List (Continued)
Number Name Unit Min/Max Default Enum Text Description R/W
