Port Functions
This section describes the parameter settings for port functions. It includes the
following sections:
■ Parameters Shared Across All Port Functions
■ Parameters Defined Separately for All Port Functions
Parameters Shared Across All Port Functions
This section defines the PCI Express and PCI capabilities parameters that are shared
for all port functions. It includes the following capabilities:
■ Device
■ Error Reporting
■ Link
■ Slot
■ Power Management
1 Some of these parameters are stored in the Common Configuration Space Header.
Text in green are links to these parameters stored in the Common Configuration Space
Header.
Reference clock
frequency
100 MHz
125 MHz
The
PCI Express Base Specification 2.1 requires a
100 MHz
±300 ppm reference clock. The 125 MHz reference clock is
provided as a convenience for systems that include a 125 MHz clock
source.
Use 62.5 MHz
Application Layer
clock
On/Off This is a special power saving mode available only for Gen1 ×1 variants.
Use deprecated RX
Avalon-ST data byte
enable port (rx_st_be)
On/Off When enabled the variant includes the deprecated
rx_st_be signals.
Number of functions 1–8 Specifies the number of functions that share the same link.
Table 3–1. System Settings for PCI Express (Part 3 of 3)
Parameter Value Description
