III-4
[4] AUTO/MANUAL switch
Used to select the automatic or manual mode of operation. Turned to
“
(MANUAL)” to cause the machine to make one cut. Turned to “
(AUTO)” to cause the machine to automatically operate according to the
preset cutting data.
NOTE
O When the machine is first started in the MANUAL mode and then switched to
the AUTO mode during the downfeeding of the sawhead, the first cut is not
counted, but the subsequent cuts are counted as the number of pieces cut
during automatic operation. This function can be used for the machine to
automatically cut the work after it trims the end of the work.
O If the switch is turned to MANUAL during its automatic operation, the machine
stops immediately. When the switch is turned to MANUAL during cutting, the
machine stops after completing the current cut.
[5] BLADE DRIVE button
Starts the saw blade running, turns on the cutting fluid, and lowers the
sawhead.
NOTE
O There are several necessary conditions and confirmations to be met before
starting the cutting operation. Refer to “Manual operation” and “Automatic
operation” in Part IV, Operation.
[6] EMERGENCY STOP button
Brings the machine to a total stop immediately.
The button locks when pressed and must be pulled to unlock it.
[7] BLADE UP button
Pressed to stop the saw blade running, and pressed and held to raise
the sawhead.
[8] BLADE DOWN button
Pressed and held to rapidly lower the sawhead.
When the quick approach feeler touches the work, the sawhead
automatically changes to the downfeed speed preset with the FLOW
CONTROL dial.
NOTE
O The button is enabled only when the AUTO/MANUAL switch is turned to
MANUAL.
