III-5
[9] FRONT VISE OPEN button
With the sawhead at the upper limit, pressed and held to open the front
vise over the full stroke.
With the sawhead in any other position, pressed to open the front vise
slightly. When the front vise is already opened, it does not open any
more at the depression of the button.
NOTE
O The button is enabled only when the AUTO/MANUAL switch is turned to
MANUAL.
[10] FRONT VISE CLOSE button
Pressed and held to close the front vise and illuminate the FRONT VISE
CLOSE light.
NOTE
O The button is enabled only when the AUTO/MANUAL switch is turned to
MANUAL.
[11] FRONT VISE CLOSE light
Illuminated to indicate that the front vise is closed and extinguished to
indicate that the front vise is opened.
[12] REAR VISE OPEN button
With the sawhead at the upper limit, pressed and held to open the rear
vise over the full stroke.
With the sawhead in any other position, pressed to open the rear vise
slightly. When the rear vise is already opened, it does not open any
more at the depression of the button.
NOTE
O The button is enabled only when the AUTO/MANUAL switch is turned to
MANUAL.
[13] REAR VISE CLOSE button
Pressed and held to close the rear vise and illuminate the REAR VISE
CLOSE light.
NOTE
O The button is enabled only when the AUTO/MANUAL switch is turned to
MANUAL.
[14] REAR VISE CLOSE light
Illuminated to indicate that the rear vise is closed and extinguished to
indicate that the rear vise is opened.
