III-16
Chip conveyor
The chip conveyor is hydraulically driven and operated only when the
sawhead is lowering.
When removing the chips after cleaning the machine, move the
sawhead down to the lower limit, and press the BLADE DOWN button.
The chip conveyor operates as long as the BLADE DOWN button is
pressed and held.
WARNING
O Never reach into the chip conveyor when
the machine is operating. Before
removing foreign matter from the chip
conveyor, be sure to turn the machine
circuit breaker switch to OFF and turn off
the shop circuit breaker switch.
NOTICE
āWhen a trimming or solid material other than chips enters the chip conveyor, it
may eat into the spiral or damage the spiral. Take care so that nothing other
than chips should fall into the chip conveyor.
