Amada HFA-400 - Page 87

IV-9
8 Pull down the left-
hand and right-hand
saw blade insert
clamp levers to open
the saw blade inserts.
  
 
9 Turn the saw blade
tension lever to the
“
” position.
The driven wheel
moves to the right.
SAW BLADE
TENSION LEVER
10 Loosen the wire brush
lock lever, and lower
the wire brush and
wire brush cover.
 

 
 
11 Install the saw blade
on the drive and
driven wheels with the
cutting edge facing
down.
