Ametek Sorensen XG - Table 5-2 Db-9 Pinouts

Remote Operation
5-4 M370430-01 Rev B
RS-232 Communication Cable with RJ-45 to DB-9
Communication control cable with DB-9 connector (male) on the PC
side and RJ-45 shielded connector on the power supply. The cable
length should be 9.84 feet (3 m) or longer.
Table 5-2 DB-9 Pinouts
Pin
Name
Description
1
NC
No connection
2
RX
Receive data
Twisted
pair
3
TX
Transmit data
4
NC
No connection
5
GND
Ground
6, 7, 8, 9
NC
No connection
Table 5-3 RJ-45 Pinouts
Pin
Name
Description
1
RX
Receive data
Twisted
pair
2
TX
Transmit data
3, 4, 5, 6
NC
No connection
7
GND
Ground
8
NC
No connection
