Specifications
M370430-01 Rev B
C-9
C
Common Specifications for All Models
Output Performance Specifications
Aux output
1
+5V: +0.4V, – 0.5V at 0.4A
+15V: +1.2V, – 1.4V at 0.4A
Temperature Coefficient
100 PPM/° C from rated output voltage, after a 30-minute warm-up
Drift (8 hours)
0.05% of rated output (over an 8 hour interval with constant line, load and temperature, after a 30-minute warm-up)
Hold-up Time
Typical 20 ms at any rated input line.
Transient Response Time
2
Less than 1 ms for 6 V to 60 V models. Less than 2 ms for 80 V to 600 V models
Meter Accuracy
0.5% of actual output voltage or current ± 1 count
Isolation
AC Input to Output
1350 Vac
AC Input to Chassis
1350 Vac
Output to Chassis
3
500 Va c
1. Current: 0.51A minimum guaranteed, 0.72A typically available. Overcurrent protection (each output) is automatic, non-latching. When OCP is tripped the aux voltage folds back and will
recover to nominal condition when the over current condition is removed (typ. < 0.2A).
To protect external circuits attached to the aux outputs it is recommended that customers use an appropriately rated fuse in series with the aux outputs being used.
2. Time for the output voltage to recover within 0.5% at its rated output for a load change 10–90% of rated output current. Output set point 10–100%.
3. For floating chassis ground applications, please contact applications engineering for system design assistance.
