Local Operation
3-16 M370430-01 Rev B
5. Once the desired value has been set, press the rotary
Adjust/Enter control to commit the setting.
Important: The control circuits have been designed to allow you to set the
output voltage up to 105% over the model-rated maximum value. The power
supply will operate within these extended ranges, but full performance to
specification is not guaranteed.
Quick Tip Remote
operation uses these
SCPI commands. See
page 5-1.
The SCPI command (s) for these instructions are:
[[:]SOURce[<channel>]]:VOLTage[:LEVEl][:IMMediate]
[:AMPLitude]
Important: The maximum and minimum setting values of the output voltage
are limited by the Over Voltage Protection and Under Voltage Protection
settings.
To set the current set point (I
SET
)
:
1. Turn the 9-position mode control to the AMPS position or
press the rotary Adjust/Enter control if the 9-position mode
control is already at the AMPS position.
The voltage set point is blinking in the output voltage display. The
output current will be displayed in the output current display.
2. Set the desired current value using the rotary Adjust/Enter
control.
3. Press the rotary Adjust/Enter control to transition to Fine
Adjust mode.
The set point blinks faster to indicate fine adjust tracking mode.
4. Set the desired current value using the rotary Adjust/Enter
control.
5. Once the desired value has been set, press the rotary
Adjust/Enter control to commit the setting.
Important: The control circuits have been designed so that output current can
be set up to 105% over the model-rated maximum values. The power supply
will operate within these extended ranges, but full performance to specification
is not guaranteed.
The SCPI command (s) for these instructions are:
[[:]SOURce[<channel>]]:CURRent[:LEVEl][:IMMediate]
[:AMPLitude]
