WORKSHOP MANUAL
When the battery is discharged, the machine can still be controlled using acable.
The battery warning and error are then indicated also during control (if the controller is activated).
When and as long as the infrared light emitter is connected via acable to the machine’s control unit and the ignition is
in the “I” position, the red LED must be ashing or illuminated.
Automatic pairing function
• If you wish to control the machine via the infrared remote control, you must rst perform amutual assignment of addresses. This
is only necessary when registering anew infrared remote control to the machine.
• Connect the cable to the emitter.
• Turn the ignition key to the “I” position.
• After about 3 seconds, you can disconnect the cable.
• The cable is not required for operation with the infrared remote control.
Indicator lamp Reason
The green and red LEDs are both ashing rapidly. The infrared remote control is paired with the control unit of the
machine.
Note:
This process normally takes amaximum of 3 seconds. If the ashing is longer or even persistent, apairing problem occurred:
• cable break in one of the signal connections,
• short circuit in one of the signal connections,
6.1.3.3 Cable connection
1 Spiral cable connector / protective cover fastener
2 Solar cells / transmission elements
