146 ARR1575

557D284

557D285

557D286

557D287

7 Front drum

7.4.4 Installation of the drum rubber-metal

elements

Apply blue adhesive on the screws.

Install new rubber-metal elements on the centre beam. The

tightening torque is 50 Nm.
