Ammann ARR 1575 - Swinging Joint

69ARR1575
557D573
557D575
557D576
557D574
1
1
WORKSHOP MANUAL
5.4.10 Swinging joint
Remove the swinging support (Chapter 5.4.8).
Remove the steering piston (Chapter 5.4.9).
Cut the hose bundle ties.
Place aprotective plate (e.g. aluminium) at the bottom and top
between the chassis and the hose bundle.
Remove the screws of the swinging joint.
Remove the cap.
