Ammann ARR 1575 - Swinging Support

To Next Page

To Previous Page

58 ARR1575

557D535

557D536

5 Frame

5.4.8 Swinging support

Removal

Mount alock against cranking.

Place the hydraulic jack to the centre of the swinging joint.

Slightly unload the roller.
