WORKSHOP MANUAL
3.3 Technical data
ARR 1575
U.S. EPA Tier 4f
640 850
Dimensions
Drum width (mm) 640 850
Weight
Operating weight EN 500-1+A1 (CECE) kg (lb) 1340 (2950) 1440 (3170)
Operating load EN 500-1+A1 (CECE) on the front axis kg (lb) 730 (1610) 780 (1720)
Operating load EN 500-1+A1 (CECE) on the rear axis kg (lb) 610 (1340) 660 (1460)
Weight of the half volume of operating uids kg (lb) 10 (20) 10 (20)
Operating weight ISO 6016 kg (lb) 1350 (2980) 1450 (3200)
Maximum weight with accessories kg (lb) 1450 (3200) 1450 (3200)
Riding qualities
Maximum transport speed km/h (mph) 2.8 (1.7) 2.8 (1.7)
Working speed 1.4 (0.9) 1.4 (0.9)
Climbing ability without vibration % 30 30
Climbing ability with vibration % 25 25
Lateral static stability % 80 80
Lateral stability when driving without vibration % 25 25
Lateral stability when driving with vibration % 15 15
Turning radius, inner (edge) mm (in) 1540 (60.6) 1440 (56.7)
Turning radius, outer (contour) mm (in) 2190 (86.2) 2290 (90.2)
Drive type - Hydrostatic
Number of driving axles - 2
Oscillation angle ° ±7
Steering angle ° ±30
Steering
Steering type - Joint
Steering control - Hydraulic
Linear hydraulic motors - 2
Engine
Manufacturer - YANMAR
Type - 3TNV80F-SPAMM
Power according to ISO 3046-1 kW (HP) 14.6 (20)
Number of cylinders - 3
Cylinder capacity cm³ (cu in) 1266 (77)
Nominal speed min
-1
(RPM) 2400
Maximum torque Nm (ft lb)/rpm 68.4/1800
Fuel consumption in common operation l/h (gal US/h) 3.2 (0.8)
The engine complies with emission regulations - U.S. EPA Tier 4 Final
Engine cooling system - Liquid
Brakes
Operating - Hydrostatic
Parking - Mechanical multi-disc
