Ammann ARR 1575 - Speeds and Pressures

318 ARR1575
18 Troubleshooting
18.2.10 Speeds and pressures
after 5 min. after 60 min.
Diesel engine speed rpm 2415 ±25 2405 ±25
Vibration speed front low rpm 2250 ± 150 2250 ± 150
rear low rpm 2250 ± 150 2250 ± 150
front high rpm 2250 ± 150 2250 ± 150
rear high rpm 2250 ± 150 2250 ± 150
Supply pressure bar 21 ±2 21 ±2
Travel working pressures forward bar 100 ±20 100 ±20
reverse bar 100 ±20 100 ±20
Vibration drive pressures * low amplitude bar 105 ±55 65 ±15
high amplitude bar 110 ±50 80 ±20
Maximum travel pressure Forward locking bar - 330 ±15
Reverse locking bar - 330 ±15
Maximum pressure Steering bar - 67 ±7
Vibration bar - 220 ±10
* During the rst start, only low amplitude vibration can be used for the rst 2 minutes.
