WORKSHOP MANUAL

5.4.6.1 Replacement of bonnet hinges

Remove the bonnet (Chapter 5.4.6).

Remove the hinge screws.

Replace the bonnet hinge.

Apply blue adhesive on the screws.

Mount the hinges using screws. The tightening torque is 50 Nm.
